RC154 142 kN Capacity, 101 mm Stroke, General Purpose Hydraulic Cylinder

Enerpac RC154 is a robust single-acting, spring-return hydraulic cylinder engineered for high-capacity lifting and pushing tasks in industrial maintenance, construction, and general-purpose applications. Offering a 15.7-ton (142 kN) capacity over a 101 mm stroke, this alloy steel model operates at up to 10,000 psi with features like a grooved plunger for saddle mounting, relief valves for safety, and a corrosion-resistant baked enamel finish, ensuring durability and efficiency in demanding environments.

• Product Overview
  • Name: Enerpac RC154 General Purpose Hydraulic Cylinder
  • Type: Single-acting, spring-return solid plunger cylinder
  • Primary Applications: Industrial lifting, pushing, bolting, and maintenance tasks
  • Force Output: 15.7 tons (142 kN)
  • Stroke: 101 mm (3.98 in)
  • Retraction Mechanism: Spring return
  • Operating Pressure: Maximum 10,000 psi (700 bar)
  • Collapsed Height: 220 mm (8.66 in)
• Technical Specifications
  • Capacity: 15.7 tons (142 kN)
  • Maximum Operating Pressure: 10,000 psi (700 bar)
  • Stroke: 101 mm (3.98 in)
  • Collapsed Height (A): 220 mm (8.66 in)
  • Extended Height (B): 321 mm (12.64 in)
  • Outside Diameter (D): 70 mm (2.75 in)
  • Bore Diameter (E): 50.8 mm (2.00 in)
  • Plunger Diameter (F): 41.3 mm (1.63 in)
  • Effective Area (Advance): 20.3 cm² (3.14 in²)
  • Oil Capacity (Advance): 205 cm³ (12.52 in³)
  • Weight: 6 kg (13.2 lbs)
  • Saddle Diameter (J): 35 mm (1.38 in)
  • Saddle Protrusion from Plunger (K): 9 mm (0.35 in)
  • Collar Thread (W): 2 3/4"-16 UN
  • Collar Thread Length (X): 30 mm (1.19 in)
  • Series: RC Series General Purpose Cylinders
• Key Features
  • Single-acting design with spring return for efficient and controlled operation
  • Alloy steel construction for superior strength and longevity
  • Grooved plunger allows for easy mounting of tilt saddles without additional hardware
  • Built-in relief valves prevent over-pressurization for enhanced safety
  • Baked enamel finish provides corrosion resistance in harsh conditions
  • Chrome-plated plunger ensures smooth action and reduced wear
  • Includes CR-400 coupler and dust cap for immediate compatibility and protection
  • Plunger wiper minimizes contamination to extend service life
