P842 Two Speed, Lightweight Hydraulic Hand Pump, 2540 cm3 Usable Oil, For use with Double-Acting Cylinders

Enerpac P842 Two Speed Lightweight Hydraulic Hand Pump 2540 cm3 Usable Oil For use with Double-Acting Cylinders is a compact, manually operated hydraulic pump designed for precise control in industrial maintenance and assembly tasks requiring double-acting cylinder operation. Featuring two-stage speed technology for rapid low-pressure advance (up to 400 psi) transitioning to high-pressure efficiency up to 10,000 psi, this lightweight tool includes a 4-way 3-position manual valve for advance/hold/return functions, 2540 cm³ (155 in³) usable oil reservoir in a durable glass-filled nylon construction, and ergonomic handle for fatigue-free operation, ensuring reliable performance without external power sources.

• Model Number: P842
• Product Type: Lightweight Hydraulic Hand Pump (Two-Speed, 4-Way Valve)
• Color: Silver/Gray
• Material: Glass-Filled Nylon Reservoir with Nylon Encapsulated Aluminum Pump Base and Hardened Steel Components
• Capacity: 10,000 psi (700 bar) Maximum Operating Pressure; Two-Stage (First Stage: 400 psi, Second Stage: 10,000 psi)
• Oil Capacity: 2540 cm³ (155 in³) Usable
• Valve Type: 4-Way, 3-Position Manual (Advance/Hold/Return) for Double-Acting Cylinders
• Flow Rate: 2.40 in³/stroke (39 cm³/stroke) First Stage; 0.25 in³/stroke (4.1 cm³/stroke) Second Stage; 1" (25 mm) Stroke Length
• Weight (Net): 5 kg / 11 lbs
• Dimensions: Length: 552 mm (21.75"), Width: 45 mm (1.78"), Height: 133 mm (5.25"); Handle Length: 300 mm (11.8")
• Overview: Compact two-speed hand pump for efficient double-acting applications; ideal for field or workshop use with lightweight design, high-pressure capability, and simple manual controls for precise lifting and positioning
• Key Features:
  • Two-stage operation enables quick initial advance at low pressure for faster setup, switching to high force for controlled operation up to 10,000 psi
  • Durable glass-filled nylon reservoir resists corrosion and damage, with sight glass for easy oil level monitoring
  • Ergonomic handle and 1" stroke length reduce operator fatigue during extended use
  • Compatible with Enerpac RC-series double-acting cylinders and standard hydraulic hoses for versatile industrial tasks
  • Lightweight and portable for easy transport to remote sites, with no external power required
