P392 Two Speed, Lightweight Hydraulic Hand Pump, 901 cm3 Usable Oil

Enerpac P392 Two Speed Lightweight Hydraulic Hand Pump 901 cm3 Usable Oil is a compact, manually operated hydraulic pump designed for precise control in industrial maintenance and assembly tasks requiring double-acting cylinder operation. Featuring two-stage speed technology for rapid low-pressure advance (up to 200 psi) transitioning to high-pressure efficiency up to 10,000 psi, this lightweight tool includes a 4-way 3-position manual valve for advance/hold/return functions, 901 cm³ (55 in³) usable oil reservoir in a durable glass-filled nylon construction, and ergonomic handle for fatigue-free operation, ensuring reliable performance without external power sources.

• Model Number: P392
• Product Type: Lightweight Hydraulic Hand Pump (Two-Speed, 4-Way Valve)
• Color: Silver/Gray
• Material: Glass-Filled Nylon Reservoir with Nylon Encapsulated Aluminum Pump Base and Hardened Steel Components
• Capacity: 10,000 psi (700 bar) Maximum Operating Pressure; Two-Stage (First Stage: 200 psi / 13.8 bar, Second Stage: 10,000 psi / 700 bar)
• Oil Capacity: 901 cm³ (55 in³) Usable
• Valve Type: 4-Way, 3-Position Manual (Advance/Hold/Return) for Double-Acting Cylinders
• Flow Rate: 2.40 in³/stroke (39 cm³/stroke) First Stage; 0.25 in³/stroke (4.1 cm³/stroke) Second Stage; 1" (25 mm) Stroke Length
• Weight (Net): 4.6 kg / 10.1 lbs
• Dimensions: Length: 533 mm (21"), Width: 121 mm (4.75"), Height: 178 mm (7")
• Overview: Compact two-speed hand pump for efficient double-acting applications; ideal for field or workshop use with lightweight design, high-pressure capability, and simple manual controls for precise lifting and positioning
• Key Features:
  • Two-stage operation enables quick initial advance at low pressure for faster setup, switching to high force for controlled operation up to 10,000 psi
  • Durable glass-filled nylon reservoir resists corrosion and damage, with sight glass for easy oil level monitoring
  • Ergonomic handle and 1" stroke length reduce operator fatigue during extended use
  • Internal pressure relief valve provides overload protection, factory-set for safety
  • Compatible with Enerpac RC-series double-acting cylinders and standard hydraulic hoses for versatile industrial tasks
