KB-10A Rotary Screw Air Compressor, 10 Hp

KB-10A is a belt-driven, oil-injected rotary screw air compressor from Shanghai Kangkeer Compressor Co., Ltd. (brand: KKR), designed for stationary industrial applications. With 10 HP power, it offers reliable, efficient compressed air delivery for workshops, manufacturing, automotive repair, and general pneumatic tools. Key advantages include low noise levels, air cooling for simple operation, and robust construction for continuous duty in demanding environments.

Key Performance Specifications

• Motor Power: 10 HP (7.5 kW)
• Free Air Delivery:
  • 1.1 m³/min (38.8 CFM) at 0.7 MPa (101 PSI)
  • 1.0 m³/min (35.3 CFM) at 0.8 MPa (116 PSI)
  • 0.9 m³/min (31.8 CFM) at 1.0 MPa (145 PSI)
  • 0.8 m³/min (28.2 CFM) at 1.2 MPa (174 PSI)
• Maximum Working Pressure: 1.2 MPa (174 PSI)
• Drive Type: Belt Driven
• Lubrication Style: Oil-Injected

Physical and Environmental Specifications

• Dimensions (L × W × H): 890 × 630 × 920 mm (35.0 × 24.8 × 36.2 in)
• Weight: 240 kg (529 lbs)
• Configuration: Stationary, Tankless (base-mounted)
• Power Supply: 220V / 380V / 415V, 3-phase AC (50/60 Hz)
• Noise Level: 62 ± 2 dB(A)
• Cooling Type: Air Cooling
• Operating Temperature: 0–40°C (32–104°F, no condensation)

Key Features

• Construction: Robust screw-type design with high-efficiency airend for low vibration and long life
• Control System: Standard on/off control with pressure regulation
• Intake Filter: Integrated for clean air supply
• Safety Features: Overload protection, emergency stop, and pressure relief valve
• Applications: Suitable for paint workshops, small machining, fabrication, and general industrial pneumatic needs
• Standards Compliance: CE marked; RoHS compliant components
