P84 Two Speed, ULTIMA Steel Hydraulic Hand Pump, 2200 cm3 Usable Oil, For use with Double-Acting Cylinders

Enerpac P84 Two Speed ULTIMA Steel Hydraulic Hand Pump 2200 cm3 Usable Oil For use with Double-Acting Cylinders is a durable, manually operated hydraulic pump designed for precise control in industrial maintenance and assembly tasks requiring double-acting cylinder operation. Featuring two-stage speed technology for rapid low-pressure advance (up to 500 psi) transitioning to high-pressure efficiency up to 10,000 psi, this all-steel construction tool includes a 4-way 3-position manual valve for advance/hold/return functions, 2200 cm³ (134 in³) usable oil reservoir with vent-free design to eliminate spills, and ergonomic handle with reduced effort for fatigue-free operation, ensuring reliable performance without external power sources in demanding environments.

• Model Number: P84
• Product Type: ULTIMA Steel Hydraulic Hand Pump (Two-Speed, 4-Way Valve)
• Color: Silver/Gray
• Material: All-Steel Construction with Chrome-Plated Plunger and Wiper System
• Capacity: 10,000 psi (700 bar) Maximum Pressure (1st Stage: 500 psi / 34 bar; 2nd Stage: 10,000 psi / 700 bar)
• Oil Capacity: 2200 cm³ (134 in³) Usable
• Valve Type: 4-Way, 3-Position Manual (Advance/Hold/Return) for Double-Acting Cylinders
• Flow Rate: 1.0 in³/stroke (16.4 cm³/stroke) 1st Stage; 0.25 in³/stroke (4.1 cm³/stroke) 2nd Stage; 25 mm (1") Stroke Length
• Handle Effort: 65 lbs (29.5 kg) at 10,000 psi
• Ports: 3/8-18 NPTF
• Weight (Net): 5 kg / 11 lbs
• Dimensions: Length: 509 mm (20.06"), Width: 83 mm (3.25"), Height: 184 mm (7.25")
• Overview: Durable two-speed steel hand pump for efficient double-acting applications; ideal for field or workshop use with lightweight design, high-pressure capability, and simple manual controls for precise lifting and positioning
• Key Features:
  • Two-stage operation enables quick initial advance at low pressure for faster setup, switching to high force for controlled operation up to 10,000 psi
  • All-steel construction with chrome-plated plunger and wiper system ensures long-lasting performance and corrosion resistance
  • Ergonomic handle and reduced effort design minimize operator fatigue during extended use
  • Vent-free reservoir eliminates oil spills and contamination, with sight glass for easy level monitoring
  • Compatible with Enerpac RC-series double-acting cylinders and standard hydraulic hoses for versatile industrial tasks
