IQI-PS-1 IQI Power 1

Ingersoll Rand IQI-PS-1 is a compact single-channel power supply module engineered for reliable DC power delivery and signal management in cordless tool ecosystems, specifically compatible with IQV series 20V lithium-ion tools and RTS controllers. Providing stable 20V output up to 5A with integrated overcurrent protection, this module ensures uninterrupted operation in assembly lines, automotive production, and maintenance environments, featuring a DIN rail mount for seamless integration and LED status indicators for quick diagnostics. With short-circuit and thermal safeguards, it supports error-proofing workflows by maintaining consistent power to tools, minimizing downtime, and enabling safe, efficient charging cycles without compromising performance.

Key Performance Specifications

• Output Voltage: 20V DC (stable for IQV tools)
• Output Current: Up to 5A continuous (surge up to 8A)
• Channels: 1 (expandable via daisy-chain)
• Efficiency: >90% (switch-mode design)
• Protection: Overcurrent (5.5A trip), short-circuit, thermal shutdown (85°C max)
• Input Voltage: 100-240V AC, 50/60 Hz

Physical and Environmental Specifications

• Dimensions: 100 mm W x 80 mm H x 50 mm D (compact DIN rail profile)
• Weight: 0.4 kg (0.88 lbs)
• Mounting: 35 mm DIN rail (standard clip included)
• Operating Temperature: -4°F to 140°F (-20°C to 60°C); suitable for industrial use
• Cooling: Passive convection (fanless for quiet operation)
• Connections: IQI quick-disconnect input/output; AC power cord (1.8 m)
• Storage Conditions: Dry environment to prevent corrosion; indefinite shelf life

Key Features

• Stable 20V Delivery: Switch-mode regulation provides clean DC power to IQV tools, preventing voltage fluctuations that could affect torque accuracy
• Integrated Protection: Automatic overcurrent, short-circuit, and thermal safeguards protect tools and modules during high-demand operations
• LED Status Indicators: Multi-color LEDs for power on, output active, fault, and overload status, enabling instant diagnostics without additional tools
• DIN Rail Compatibility: Tool-free mounting for organized control panels, supporting scalable setups with multiple power modules
• Universal AC Input: Wide-range 100-240V compatibility for global deployment, with EMI filtering for noise-free environments
• Applications: Optimized for powering IQV cordless tools in automotive assembly, electronics production, and general maintenance; excels in error-proofing stations requiring reliable single-channel DC supply
