FSH14, 125 kN, Hydraulic Industrial Spreader, 80 mm Maximum Spread

Enerpac FSH14 is a lightweight, high-capacity hydraulic industrial spreader designed for safe, controlled separation of seized or corroded flanges in pipelines, valves, pumps, and industrial maintenance applications without risking bolt damage or flare-up. This single-acting, spring-return system features an ergonomic tool with adjustable jaws and a friction-free interlocking wedge design for parallel spreading up to 80 mm, enabling reliable performance at up to 10,000 psi while minimizing downtime through simple, low-maintenance operation and easy setup in tight spaces.

• Model: FSH14 (Hydraulic Industrial Spreader, FS Series)
• Capacity: 125 kN (14 tons) spreading force
• Maximum Spread: 80 mm (3.16 in.)
• Access Gap/Tip Clearance: 6 mm (0.24 in.)
• Stroke: 38 mm (1.50 in.)
• Maximum Operating Pressure: 700 bar (10,000 psi)
• Jaw Adjustment Range: 70–216 mm (2.75–8.50 in.)
• Maximum Flange Thickness: 2 x 57 mm (2 x 2.25 in.)
• Stud Size Compatibility: 19–28 mm (0.75–1.13 in.)
• ASA Flange Rating: 150–2,500 psi
• Pipe Size Compatibility: 63–356 mm (2.50–14 in.)
• Oil Capacity: 78 cm³ (4.76 in³)
• Weight: 7.12 kg (15.70 lb.)
• Dimensions: Height 196 mm (7.71 in.), Width 152 mm (6.00 in.), Depth 88 mm (3.45 in.)
• Spreader Head Type: Single-acting, spring return with RC series cylinder; interlock wedge design for parallel, flare-free spreading
• Operator Feedback: Visual spread completion indicator
• Maintenance Features: Tool-free jaw adjustment; corrosion-resistant steel construction; annual seal inspection recommended; replaceable wedges
• Additional Features: Lightweight ergonomic design for ease of use; eliminates flange damage and spreading arm failure risk; safety lock mechanism; complies with industry standards for hydraulic tools
